Mapping Numbers

Mapping Numbers

Summary: Connect phone numbers to your agent using SignalWire's SWML Script resources.

Overview

SignalWire uses SWML Script resources to connect phone numbers to your agent. When a call comes in, SignalWire fetches SWML from your agent's URL and executes it.

Caller Flow

Step 1: Create a SWML Script Resource

1. Log in to SignalWire dashboard
2. Navigate to My Resources in the left sidebar
3. Click Script
4. Click New SWML Script
5. Fill in the fields:
   • Name: Give your script a name (e.g., "my-agent")
   • Handle Calls Using: Select External URL
   • Primary Script URL: Enter your agent URL with credentials
     • Format: https://user:pass@your-domain.com/agent
6. Click Create

New SWML Script

Step 2: Add a Phone Number or Address

After creating the script, you'll see the resource configuration page:

Back to Resources

1. Click the Addresses & Phone Numbers tab
2. Click + Add
3. Choose your address type:
   • Phone Number: For receiving calls from regular phones (PSTN)
   • SIP Address: For receiving SIP calls
   • Alias: For referencing this resource by a custom name
4. Follow the prompts to select or purchase a phone number
5. Your number is now connected to your agent!

Add an Address

Step 3: Test Your Setup

1. Ensure your agent is running locally
2. Ensure ngrok is running (if using tunneling)
3. Call your SignalWire phone number
4. Hear your agent respond!

URL Format

Your agent URL structure depends on your setup:

Single Agent:

https://your-server.com/

Multiple Agents:

https://your-server.com/support
https://your-server.com/sales
https://your-server.com/billing

With Authentication (recommended):

https://user:pass@your-server.com/

Using ngrok for Development

# Start your agent locally
python my_agent.py

# In another terminal, start ngrok
ngrok http 3000

# Use the ngrok HTTPS URL in SignalWire
# https://abc123.ngrok.io

For a static URL that doesn't change on restart:

ngrok http --url=https://your-name.ngrok-free.app 3000

Basic Authentication

The SDK automatically generates authentication credentials on startup:

Agent 'my-agent' is available at:
URL: http://localhost:3000
Basic Auth: signalwire:7vVZ8iMTOWL0Y7-BG6xaN3qhjmcm4Sf59nORNdlF9bs (source: generated)

For persistent credentials, set environment variables:

export SWML_BASIC_AUTH_USER=signalwire
export SWML_BASIC_AUTH_PASSWORD=your-secure-password

In SignalWire, use URL with credentials:

https://signalwire:your-secure-password@your-server.com/

Multi-Agent Server

Run multiple agents on one server:

from signalwire_agents import AgentServer

server = AgentServer()

# Register agents at different paths
server.register(SupportAgent(), "/support")
server.register(SalesAgent(), "/sales")
server.register(BillingAgent(), "/billing")

server.run(host="0.0.0.0", port=3000)

Create a separate SWML Script resource for each agent:

Number	SWML Script URL
+1 (555) 111-1111	https://server.com/support
+1 (555) 222-2222	https://server.com/sales
+1 (555) 333-3333	https://server.com/billing

Fallback URL

Configure a fallback for errors:

Setting	Value
Primary URL	https://your-server.com/agent
Fallback URL	https://backup-server.com/agent

Fallback triggers on:

• Connection timeout
• HTTP 5xx errors
• Invalid SWML response

Troubleshooting

Common Issues

Symptom	Likely Cause	Fix
Connection errors	ngrok not running	Start ngrok in a terminal
502 Bad Gateway	Wrong port	Match ngrok port to agent port
401 Unauthorized	Auth mismatch	Check credentials match agent output
502/503 errors	Agent crashed	Check agent terminal, restart

Test Checklist

# 1. Agent running?
curl http://localhost:3000/

# 2. Tunnel working?
curl https://your-name.ngrok-free.app/

# 3. Auth working?
curl https://user:pass@your-name.ngrok-free.app/

# 4. SWML valid?
swaig-test agent.py --dump-swml

Verification Checklist

Before going live:

• Agent is deployed and running
• HTTPS URL is accessible
• URL returns valid SWML on POST request
• Basic auth is configured
• SWML Script resource created in SignalWire
• Phone number added to SWML Script resource
• Test call completes successfully
