Swml

SWML (SignalWire Markup Language)

Summary: SWML is the JSON format that tells SignalWire how to handle calls. Your agent generates SWML automatically - you configure the agent, and it produces the right SWML.

What is SWML?

SWML (SignalWire Markup Language) is a document that instructs SignalWire how to handle a phone call. SWML can be written in JSON or YAML format - this guide uses JSON throughout. When a call comes in, SignalWire requests SWML from your agent, then executes the instructions.

SWML Flow

SWML Document Structure

Every SWML document has this structure:

{
  "version": "1.0.0",
  "sections": {
    "main": [
      { "verb1": { ...config } },
      { "verb2": { ...config } },
      { "verb3": { ...config } }
    ]
  }
}

Key parts:

• version: Always "1.0.0"
• sections: Contains named sections (usually just main)
• Each section is an array of verbs (instructions)

Common Verbs

Verb	Purpose	Example
answer	Answer the incoming call	{"answer": {}}
ai	Start AI conversation	{"ai": {...config}}
connect	Transfer to another number	{"connect": {"to": "+1..."}}
play	Play audio file	{"play": {"url": "..."}}
record_call	Record the call	{"record_call": {"format": "mp4"}}
hangup	End the call	{"hangup": {}}

A Complete SWML Example

Here's what your agent generates:

{
  "version": "1.0.0",
  "sections": {
    "main": [
      {
        "answer": {}
      },
      {
        "ai": {
          "prompt": {
            "text": "# Role\nYou are a helpful customer service agent.\n\n# Guidelines\n- Be professional\n- Be concise"
          },
          "post_prompt": "Summarize what was discussed",
          "post_prompt_url": "https://your-agent.com/post_prompt",
          "SWAIG": {
            "defaults": {
              "web_hook_url": "https://your-agent.com/swaig"
            },
            "functions": [
              {
                "function": "get_balance",
                "description": "Get the customer's account balance",
                "parameters": {
                  "type": "object",
                  "properties": {
                    "account_id": {
                      "type": "string",
                      "description": "The account ID"
                    }
                  },
                  "required": ["account_id"]
                }
              }
            ]
          },
          "hints": ["account", "balance", "payment"],
          "languages": [
            {
              "name": "English",
              "code": "en-US",
              "voice": "rime.spore"
            }
          ],
          "params": {
            "end_of_speech_timeout": 500,
            "attention_timeout": 15000
          }
        }
      }
    ]
  }
}

The ai Verb in Detail

The ai verb is the heart of voice AI agents. Here's what each part does:

{
  "ai": {
    "prompt": {},            // What the AI should do (system prompt)
    "post_prompt": "...",    // Instructions for summarizing the call
    "post_prompt_url": "...",// Where to send the summary
    "SWAIG": {},             // Functions the AI can call
    "hints": [],             // Words to help speech recognition
    "languages": [],         // Voice and language settings
    "params": {},            // AI behavior parameters
    "global_data": {}        // Data available throughout the call
  }
}

prompt

The AI's system prompt - its personality and instructions:

{
  "prompt": {
    "text": "You are a helpful assistant..."
  }
}

Or using POM (Prompt Object Model):

{
  "prompt": {
    "pom": [
      {
        "section": "Role",
        "body": "You are a customer service agent"
      },
      {
        "section": "Rules",
        "bullets": ["Be concise", "Be helpful"]
      }
    ]
  }
}

SWAIG

Defines functions the AI can call:

{
  "SWAIG": {
    "defaults": {
      "web_hook_url": "https://your-agent.com/swaig"
    },
    "functions": [
      {
        "function": "check_order",
        "description": "Check order status",
        "parameters": {
          "type": "object",
          "properties": {
            "order_id": {"type": "string"}
          }
        }
      }
    ]
  }
}

hints

Words that help speech recognition accuracy:

{
  "hints": ["SignalWire", "SWML", "account number", "order ID"]
}

languages

Voice and language configuration:

{
  "languages": [
    {
      "name": "English",
      "code": "en-US",
      "voice": "rime.spore"
    }
  ]
}

params

AI behavior settings:

{
  "params": {
    "end_of_speech_timeout": 500,
    "attention_timeout": 15000,
    "barge_match_string": "stop|cancel|quit"
  }
}

How Your Agent Generates SWML

You don't write SWML by hand. Your agent configuration becomes SWML:

from signalwire_agents import AgentBase


class MyAgent(AgentBase):
    def __init__(self):
        super().__init__(name="my-agent")

        # This becomes languages in SWML
        self.add_language("English", "en-US", "rime.spore")

        # This becomes prompt in SWML
        self.prompt_add_section("Role", "You are helpful.")

        # This becomes hints in SWML
        self.add_hints(["help", "support"])

        # This becomes params in SWML
        self.set_params({"end_of_speech_timeout": 500})

        # This becomes SWAIG.functions in SWML
        self.define_tool(
            name="get_help",
            description="Get help information",
            parameters={},
            handler=self.get_help
        )

When SignalWire requests SWML, the agent's _render_swml() method:

1. Collects all configuration (prompts, languages, hints, params)
2. Builds the SWAIG functions array with webhook URLs
3. Assembles the complete SWML document
4. Returns JSON to SignalWire

SWML Rendering Pipeline

SWML Rendering Pipeline

Viewing Your SWML

You can see the SWML your agent generates:

## Using curl
curl http://localhost:3000/

## Using swaig-test CLI
swaig-test my_agent.py --dump-swml

## Pretty-printed
swaig-test my_agent.py --dump-swml --raw | jq '.'

SWML Schema Validation

The SDK validates SWML against the official schema:

• Located at signalwire_agents/core/schema.json
• Catches invalid configurations before sending to SignalWire
• Provides helpful error messages

Common SWML Patterns

Auto-Answer with AI

{
  "version": "1.0.0",
  "sections": {
    "main": [
      {"answer": {}},
      {"ai": {...}}
    ]
  }
}

Record the Call

{
  "version": "1.0.0",
  "sections": {
    "main": [
      {"answer": {}},
      {"record_call": {"format": "mp4", "stereo": true}},
      {"ai": {...}}
    ]
  }
}

Transfer After AI

When a SWAIG function returns a transfer action, the SWML for transfer is embedded in the response:

{
  "response": "Transferring you now",
  "action": [
    {"transfer": true},
    {
      "swml": {
        "version": "1.0.0",
        "sections": {
          "main": [
            {"connect": {"to": "+15551234567", "from": "+15559876543"}}
          ]
        }
      }
    }
  ]
}

Next Steps

Now that you understand SWML structure, let's look at SWAIG - how AI calls your functions.
